Home > Switch Power Supply >

Mini Indoor Switch Power Supply AC100V 240V To DC 5V 10W 2A For Urban Lighting

Product Categories
ShenZhen Million-tech Co., Ltd.
Contact Now

Mini Indoor Switch Power Supply AC100V 240V To DC 5V 10W 2A For Urban Lighting

  • 1
  • 2

Place of Origin : Guangdong, China

Model Number : S-10-5

Certification : CE

Packaging Details : 3 layers of safety packaging

Price : Negotiation

MOQ : Negotiation

Payment Terms : T/T

Supply Ability : 10000pcs/month

Delivery Time : 3-10days

Output Power : 10W

Input Voltage : AC100-240V

Output Voltage : 5V

Output Frequency : 50-60Hz

Output Current : 2A

Product Name : Swtiching Power

Application : LED Strip

Efficiency : 90%

Weight : 110g

Size : 85*58*35mm

Protections : OPP OVP SCP OCP

Name : AC DC Power Module Converter

Contact Now

Mini Indoor Switching Power Supply AC100V 240V to DC 5V 10W 2A LED Light Adapter for Urban Lighting

AC 100V 240V to DC 5V 10W 2A Metal Shell Indoor Constant Voltage Switching Power Transformer Adapter for LED Display Lights

Model

S-10-5

AC input voltage range(V)

AC100-240V

AC Input current(max)

0.22A /AC220V;0.45A/AC110V

Frequency (Hz)

50/60Hz

Efficiency

90% Typ(230VACFull Load)

Inrush current(A)

Cold-start 20A/230V

Leakage current(mA)

<3mA/240VAC

Output Voltage(V)

DC 5V

Voltage Range

5V±5%

Output Current(A)

2A

Current Range (A)

0-2A

Rated Power(W)

10W

Start time,hold-up time(ms)

Ton≤1000ms,Td≥20ms @230Vac Full Load

Rise time(ms)

Typ:20ms @230Vac Full Load

Ripple/Noise(mVp-p)

120mVp-p

working Temperature (°C)

-40°C - +65°C(refer derating curve)

Storage Temperature(°C)

-20°C - +60°C

Humidity

20% - 90% RH non condensing

Over voltage Protection

>115%-135% Rated output voltage

Over load Protection

>105%-150% Auto recovery

Short circuit Protection

Latched

Size L*W*H

L70*W40*H30mm

Weight

68g

Product Description

Mini Indoor Switch Power Supply AC100V 240V To DC 5V 10W 2A For Urban Lighting

Mini Indoor Switch Power Supply AC100V 240V To DC 5V 10W 2A For Urban Lighting

Mini Indoor Switch Power Supply AC100V 240V To DC 5V 10W 2A For Urban Lighting

Mini Indoor Switch Power Supply AC100V 240V To DC 5V 10W 2A For Urban Lighting

Specification

item

value

Place of Origin

China

Guangdong

Brand Name

Megbox

Model Number

S-10-5

Output Power

10W

Output Type

Single

Input Voltage

AC100-240V

Output Voltage

5V

Output Frequency

50-60Hz

Output Current

2A

Product Name

Swtiching Power

Application

LED Strip

Warranty

2 Years

Certification

CE

Type

Constant Voltage

Efficiency

90%

Weight

68g

Size

70*40*30mm

Protections

OPP OVP SCP OCP

Name

AC DC Power Module Converter
